Automatic Jar Sticker Labeling Machine
Automatic Jar Sticker Labeling Machine is engineered for precise and high-speed labeling of round jars, containers, and bottles across food, pharmaceutical, cosmetic, and chemical industries. Designed for reliable performance, it ensures accurate label placement, reduced manual effort, and increased production efficiency while maintaining consistent labeling quality on various jar sizes.
Specifications & Features
Everything You Need to Know
Detailed technical data, salient features, and optional accessories — all in one place.
| Model No. | SVJSL 50 | SVJSL 100 |
|---|---|---|
| Direction of Movement | Left to Right | Left to Right |
| Output/Min* | Up to 50 Labels / Min. | Up to 100 Labels / Min. |
| Power Supply | 1.0 kW Single Phase 230V, 50Hz AC Supply (Can Customized as Client Need) |
1.5 kW Single Phase 230V, 50Hz AC Supply (Can Customized as Client Need) |
| MOC | Stainless Steel 304, Anodized Aluminum | Stainless Steel 304, Anodized Aluminum |
| Machine Dimension | L 2500 mm * W 1450 mm * H 1400 mm | L 3000 mm * W 2100 mm * H 1500 mm |
| Label Roll Core | 76 mm | Servo Motor |
| Label Roll Diameter | 300 mm | 76 mm |
| Jar Size | Dia. 30~90 mm for Round Shape (Special Size Can be Customized) 25 -80 Sq mm for Sqaure Shape Jar | |
| Container Size | 300 mm | |
| Bottle Height | 30~280 mm (special size can be customized) | Dia. 30~150 mm for Round Shape (Special Size Can be Customized) 25 -120 Sq mm for Sqaure Shape Jar |
| Label Dispenser Motor | Stepper Motor / Servo Motor | |
| Label Material | Self-adhesive sticker | 30~280 mm (Special Size Can be Customized |
| Stop Tolerance | +/- 1 mm. | Self-Adhesive Sticker |
| Label Height | 12 MM to 200 MM | 12 MM to 200 MM |
| Gap between Two Labels | Minimum 3 MM | Minimum 3 MM |
| Machine weight (kg) | 350 | |
| * Speed Depends on Sticker Length | 400 |
- No Jar No Label
- Fully Synchronised – Label Dispenser, Conveyor & wraparound Pressing Belt System
- Total GMP Model
- Very Smooth & Accurate Label Placement
- Strurdy Stainless Steel Frame Structure & Door
- Built In Product Counter
- Advance PLC Controlled Stepper / Servo Motor Label Dispenser Unit
- On-Line Speed Can Be Vary at Single touch Point
- Vibration Free Slat Chain Conveyor With Variable Speed Drive
- Partial Machine Guarding
- Touch Screen display(HMI)
- Built In Control Panel
- Sponge Belt For safely Label Pressing
- Auto Label Length Measurement
- Bottle Separator With Variable Speed DC Drive
- Height Adjustable Legs
Specifications & Features
Everything You Need to Know
Detailed technical data, salient features, and optional accessories — all in one place.
| Parameter | SVE-WA 40 | SVE-WA 80 | SVE-WA 150 | SVE-WA 200 |
|---|---|---|---|---|
| Output (Bottles/Min) | Up to 40 | Up to 80 | Up to 150 | Up to 200 |
| Power Supply | Single / Three Phase, 220–440V AC, 50 Hz |
|||
| Power Consumption | ~0.5 kW | ~0.75 kW | ~1.0 kW | ~1.5 kW |
| Bottle Diameter (mm) | 20 mm – 150 mm (adjustable) | |||
| Bottle Height (mm) | 30 mm – 350 mm (adjustable) | |||
| Label Length (mm) | 20 mm – 600 mm | |||
| Label Width (mm) | 10 mm – 200 mm | |||
| Label Roll Core (mm) | 76 mm (3 inch) standard | |||
| Label Accuracy | ± 0.5 mm | |||
| Machine Weight (Approx) | 180 kg | 210 kg | 260 kg | 310 kg |
| Machine Dimensions (L×W×H) | 1800×600×1400 mm | 2100×650×1400 mm | 2500×700×1500 mm | 2800×750×1500 mm |
| Drive System | Servo Motor + PLC (Siemens / Delta) | |||
| Frame Material | SS 304 / MS Powder Coated | |||
| HMI / Control | 7″ Touch Screen HMI | |||
| Compressed Air Required | Not Required (Standard Model) | |||
- Fully automatic label feeding, applying, and wrapping in one operation
- Servo-driven label dispenser for high-precision label placement (±0.5 mm)
- PLC-based control with 7″ colour touchscreen HMI — easy to operate
- Compatible with BOPP, paper, PET, PE, and PP self-adhesive labels
- Adjustable conveyor and bottle guide for quick product changeovers
- No bottle — no label feature to prevent label wastage
- SS 304 stainless steel construction — GMP and CE compliant
- Built-in label missing / short label detection alarm system
- Variable speed control — adjustable to match upstream production speed
- Suitable for round, cylindrical, and slightly oval container shapes
- Low maintenance design with easy access to all mechanical parts
- Available with single or double label-head configuration
- Label counting and batch counter on HMI panel
- Silent operation with vibration-free conveyor drive
- Can be integrated inline with filling, capping, and packaging lines
- Hot foil stamping or inkjet coder integration available on request
- Inkjet coder / TIJ printer for batch/date printing on label
- Hot foil stamping unit for metallic print on label
- Vision inspection system for label print quality verification
- Automatic bottle unscrambler for unsorted bottle feeding
- Pre-labeling air jet cleaning unit to remove dust from bottles
- Outfeed conveyor extension for downstream integration
- Bottle reject system (pneumatic pusher for rejected bottles)
- Second label head for front + back labeling on same machine
- Additional change parts kit for different bottle sizes
- Label re-winder unit for empty liner take-up
- CE-certified electrical panel upgrade (for export markets)
- Remote PLC monitoring and diagnostic access module
Better Labeling Performance
Optional Accessories
Upgrade your machine with advanced accessories for smoother operation, higher accuracy, and improved production efficiency.
Boost Productivity with Smart Add-Ons
Optional Add-ons
Enhance the machine with these optional configurations
Industries Served
Trusted Across Every Industry
Our Automatic Jar Sticker Labeling Machine is widely used across food, pharmaceutical, cosmetic, chemical, lubricant, agrochemical, and personal care industries.
